Chapter 3 Unpacking
C2000 Plus
3-14
Lift the drive by hooking the lif
ting hole. It is now ready for inst
allation.
Unpacking 2 (VFDXXXC63B-21)
Remove the eight buckles fixed on the crate with a flat-head screwdriver
, see the figure below
.
Remove the top cover
, take out the EPEs, rubber and the manual.
Figure 3-42
Figure 3-43
Figure 3-44
56
58
