Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-01-2
12-1 Descriptions of Parameter Settings
00 Drive Parameters
 You can set this parameter during operation.
00-00
AC Motor Drive Identity Code
Default: Read only
Settings Read only
00-01
AC Motor Drive Rated Current Display
Default: Read only
Settings Display by models
 Pr.00-00 displays the AC motor drive identity code. Use the following specification table to check
if Pr.00-01 setting is the rated current of the AC motor drive. Pr.00-01 corresponds to the identity
code of the AC motor drive (Pr.00-00).
 The default is the rated current for heavy duty. Set Pr.00-16 = 1 to display the rated current for
super heavy duty.
230V Models
Frame A B C
Power (kW) 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
Power (HP) 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30
Identity code
4 6 8 10 12 14 16 18 20 22
Rated current for
heavy duty (A)
5 8 11 17 25 33 49 65 75 90
Rated current for
super heavy duty (A)
3 5 8 11 17 25 33 49 65 75
Frame D E F
Power (kW) 30 37 45 55 75 90
Power (HP) 40 50 60 75 100 125
Identity code
24 26 28 30 32 34
Rated current for
heavy duty (A)
120 146 180 215 255 346
Rated current for
super heavy duty (A)
90 120 146 180 215 255
460V Models
Frame A B C
Power (kW) 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15 18.5 22 30
Power (HP) 1 2 3 5 5 7.5 10 15 20 25 30 40
Identity code
5 7 9 11 93 13 15 17 19 21 23 25
Rated current for
heavy duty (A)
3 4 6 9 10.5 12 18 24 32 38 45 60
Rated current for
super heavy duty (A)
1.7 3 4 6 9 10.5 12 18 24 32 38 45
Frame D0 D E F G
Power (kW) 37 45 55 75 90 110 132 160 185 200 200 250
Power (HP) 50 60 75 100 125 150 175 215 250 270 270 240
Identity code
27 29 31 33 35 37 39 41 43 486 486 487
Rated current for
heavy duty 481(A)
73 91 110 150 180 220 260 310 370 395 395 481
Rated current for
super heavy duty (A)
60 73 91 110 150 180 220 260 310 310 310 395
