Delta VFD220C43A-21 User Manual

Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-06-15
Fault Code
bit0 bit1 bit2 bit3 bit4 bit5 bit6
current Volt. OL SYS FBK EXI CE
0: No fault record
1: Over-current during acceleration (ocA)
●
2: Over-current during deceleration (ocd)
●
3: Over-current during steady operation (ocn)
●
4: Ground fault (GFF)
●
5: IGBT short circuit between upper bridge and
lower bridge (occ)
●
6: Over-current at stop (ocS)
●
7: Over-voltage during acceleration (ovA)
●
8: Over-voltage during deceleration (ovd)
●
9: Over-voltage at constant speed (ovn)
●
10: Over-voltage at stop (ovS)
●
11: Low-voltage during acceleration (LvA)
●
12: Low-voltage during deceleration (Lvd)
●
13: Low-voltage at constant speed (Lvn)
●
14: Low-voltage at stop (LvS)
●
15: Phase loss protection (OrP)
●
16: IGBT overheating (oH1)
●
17: Heatsink overheating (oH2)
●
18: IGBT temperature detection failure (tH1o)
●
19: Capacitor hardware error (tH2o )
●
21: Over load (oL)
●
22: Electronic thermal relay 1 protection (EoL1)
●
23: Electronic thermal relay 2 protection (EoL2)
●
24: Motor overheating (oH3) (PTC / PT100)
●
25: Interrupt error (INTR)
●
26: Over torque 1 (ot1)
●
27: Over torque 2 (ot2)
●
28: Under current (uC)
●
29: Limit error (LiT)
●
30: EEPROM write error (cF1)
●
31: EEPROM read error (cF2)
●
33: U-phase error (cd1)
●
34: V-phase error (cd2)
●
35: W-phase error (cd3)
●
36: cc (current clamp) hardware error (Hd0)
●
37: oc (over-current) hardware error (Hd1)
●
38: ov (over-voltage) hardware error (Hd2)
●
