Chapter 16 PLC Function ApplicationsMS300
730
API
EDIV
Divide binary floating point numbers
123
D
P
bit device
Word device
16-bit command
－
－
－
－
32-bit command (13 STEP)
DEDIV
Continuous
execution type
DEDIVP
Pulse
execution type
Flag signal: none
X
Y
M
K
H
KnX
KnY
KnM
T
C
D
S1
＊
＊
＊
S2
＊
＊
＊
D
＊
Notes on operand usage:
Refer to the function specifications table for each device in series
for the scope of device usage.
 S
1
: dividend. S
2
: divisor. D: quotient.
 Divides the content of the register designated by S
1
by the content of the
register designated by S
2
and stores the quotient in the register designated by
D; division is performed entirely using binary floating point numbers.
 If the source operand S
1
or S
2
designates a constant K or H, the command
converts that constant into a binary floating point number for use in division.
 When X1 = ON, divides the binary floating point number (D1, D0) by the binary
floating point number (D11, D10), and stores the quotient in the register
designated by (D21, D20).
X1
DEDIV
D0 D10 D20
 When X2 = ON, divides the binary floating point number (D1, D0) by K1,234
(which is automatically converted to a binary floating point number), and stores
the results in (D11, D10).
X2
DEDIV
D0 K1234 D10
