Chapter 16 PLC Function ApplicationsMS300
699
Sets the designated element to ON, and maintains it in an ON state, regardless of
whether the SET command is still driven. Use the RST command to set the element
as OFF.
Establish a parallel
connection to contact
B of Y0
Clear contact or register
Resets the designated element as described.
Both coil and contact are set as OFF.
Sets the current timing or count value to 0, and both the coil and
contact are set to OFF.
Sets the content value to 0.
If the RST command is not executed, the status of the designated element remains
unchanged.
Clear the contact or
register
Electrifies the designated timer coil, and the timer begins timing. The contact's action
is as follows when the timing value reaches the designated setting value (timing
value ≥ setting value):
N.O. (Normally Open) contact
N.C. (Normally Closed) contact
If the RST command is not executed, the status of the designated element remains
unchanged.
T5 timer
Set value as K1000
To Next Page
