Chapter 11 Summary of Parameter SettingsMS300
212
Pr.
Explanation
Settings
Default
3: External UP / DOWN terminal
(multi-function input terminals)
4: Pulse input without direction command
(refer to Pr.10-16 without considering direction)
6: CANopen communication card
7: Digital keypad potentiometer knob
8: Communication card (does not include CANopen card)
9: PID controller
NOTE:
HOA (Hand-Off-Auto) function is valid only when you use with
MO function setting 41 and 56 or with KPC-CC01 (optional).

00-31
Operation Command
Source
(HAND, LOCAL)
0: Digital keypad
1: External terminal
2: RS-485 communication input
3: CANopen communication card
5: Communication card (does not include CANopen card)
NOTE:
HOA (Hand-Off-Auto) function is valid only when you use with
MO function setting 41 and 56 or with KPC-CC01 (optional).
0

00-32
Digital Keypad STOP
Function
0: STOP key disabled
1: STOP key enabled
0
00-35
Auxiliary Frequency
Source
0: Master and auxiliary frequency function disabled
1: Digital keypad
2: RS-485 communication input
3: Analog input
4: External UP / DOWN key input
(multi-function input terminals)
5: Pulse input without direction command
(refer to Pr.10-16)
6: CANopen communication card
7: Digital keypad potentiometer knob
8: Communication card
0
00-36
Master and Auxiliary
Frequency Command
Selection
0: Master + auxiliary frequency
1: Master - auxiliary frequency
2: Auxiliary - master frequency
0
00-47
Output Phase Order
Selection
0: Standard
1: Exchange the rotation direction
0

00-48
Display Filter Time
(Current)
0.001–65.535 sec.
0.100

00-49
Display Filter Time
(Keypad)
0.001–65.535 sec.
0.100
00-50
Software Version (Date)
Read only
Read only
