Delta VFD2A8MS21ANSAA User Manual

Chapter 12 Descriptions of Parameter SettingsMS300
303
Settings
Functions
Descriptions
51
Selection for PLC
mode (bit 0)
PLC status
bit 1
bit 0
Disable PLC function (PLC 0)
0
0
Trigger PLC to operate (PLC 1)
0
1
Trigger PLC to stop (PLC 2)
1
0
No function
1
1
52
Selection for PLC
mode (bit 1)
53
Trigger CANopen
quick stop
When this function is enabled under CANopen control, it
changes to Quick Stop. Refer to Chapter 15 CANopen
Overview for more details.
56
Local / Remote
selection
Use Pr.00-29 to select LOCAL / REMOTE mode. When Pr.00-
29 is not set to 0, the optional digital keypad KPC-CC01
displays LOC / REM status. (Refer to Pr.00-29 for details)
bit 0
REM
0
LOC
1
58
Enable fire mode
(with RUN
command)
When fire occurs, enable this terminal to make the drive enter
the fire mode to force the drive to run. If the drive is in stop
status, enable this terminal to make the drive enter the fire
mode to force the drive to run according to Pr.06-80 settings.
(Refer to Pr.06-80, 06-81, 06-88 for details)
59
Enable fire mode
(without RUN
command)
When fire occurs, enable this terminal to make the drive enter
the fire mode.
If the drive is in stop status, enable this terminal to make the
drive enter the fire mode, but the drive does not run.
If the drive is in running status, enable this terminal to run the
drive according to Pr.06-80 settings. (Refer to Pr.06-80, 06-81,
06-88 for details)
70
Force auxiliary
frequency return to
0
Forces the auxiliary frequency return to 0 when using this
function. PID keeps operating if PID is the master frequency.
When Pr.00-35 ≠ 0, the master and auxiliary frequencies are
enabled, and then selecting this function with the terminal
effectively forces the auxiliary frequency return to 0.
71
Disable PID
function, force PID
output return to 0
When the master and auxiliary frequencies are enabled and
when using the PID function, ON: PID does not operate,
returns the integral value to 0, and forces the PID output return
to 0.
72
Disable PID
function, retain the
output value before
disabled
When the master and auxiliary frequencies are enabled, and
the PID function is enabled, ON: PID does not operate, and its
output value remains the same as the value before it was
disabled.
