Chapter 12 Descriptions of Parameter SettingsMS300
307
02-12
Multi-Function Input Mode Selection
Default: 0000
Settings
0000hFFFFh (0: N.O.; 1: N.C.)
The parameter setting is in hexadecimal.
This parameter sets the status of the multi-function input signal (0: normally open; 1: normally
closed) and it is not affected by the status of SINK / SOURCE.
bit 0–bit 6 correspond to MI1–MI7.
The default for bit 0 (MI1) is FWD terminal, and the default for bit 1 (MI2) is REV terminal. If the
MI1 and MI2 are not used as two-wire / three-wire control method, set Pr.02-00 = 0. Then set
this parameter according to the functional requirements of terminals MI1 and MI2 (referring to
Pr.02-01 and Pr.02-02).
You can change the terminal ON / OFF status through communications.
For example: MI3 is set to 1 (multi-step speed command 1) and MI4 is set to 2 (multi-step speed
command 2). Then the forward + second step speed command = 1001
2
= 9
10
.
As long as Pr.02-12 = 9 is set through communications, there is no need to wire any multi-
function terminal to run forward with the second step speed.
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
MI7
MI6
MI5
MI4
MI3
MI2
MI1
Use Pr.11-42 bit 1 to select whether FWD / REV terminal is controlled by Pr.02-12 bit 0 and bit 1.
02-13
Multi-Function Output 1 (RY1)
Default: 11
02-16
Multi-Function Output 2 (MO1)
02-17
Multi-Function Output 3 (MO2)
Default: 0
Settings
12-1-1-53
0: No function
12-1-1-54
1: Indication during RUN
12-1-1-55
2: Operation speed reached
12-1-1-56
3: Desired frequency reached 1 (Pr.02-22)
12-1-1-57
4: Desired frequency reached 2 (Pr.02-24)
12-1-1-58
5: Zero speed (Frequency command)
12-1-1-59
6: Zero speed including STOP (Frequency command)
12-1-1-60
7: Over-torque 1 (Pr.06-0606-08)
12-1-1-61
8: Over-torque 2 (Pr.06-0906-11)
12-1-1-62
9: Drive is ready
12-1-1-63
10: Low voltage warning (Lv) (Pr.06-00)
12-1-1-64
11: Malfunction indication
12-1-1-65
13: Overheat warning (Pr.06-15)
12-1-1-66
14: Software brake signal indication (Pr.07-00)
12-1-1-67
15: PID feedback error (Pr.08-13, 08-14)
12-1-1-68
16: Slip error (oSL)
12-1-1-69
