Chapter 12 Descriptions of Parameter SettingsMS300
336
 Summary of Function Settings
Settings
Functions
Descriptions
0
Output frequency (Hz)
Maximum frequency Pr.01-00 is processed as 100%.
1
Frequency command (Hz)
Maximum frequency Pr.01-00 is processed as 100%.
2
Motor speed (Hz)
Maximum frequency Pr.01-00 is processed as 100%.
3
Output current (rms)
(2.5 × drive rated current) is processed as 100%.
4
Output voltage
(2 × motor rated voltage) is processed as 100%.
5
DC bus voltage
230 V models: 450V = 100%
460 V models: 900V = 100%
575 V models: 1125V = 100%
6
Power factor
-1.000–1.000 = 100%
7
Power
(2 × drive rated power) is processed as 100%.
8
Output torque
Full-load torque = 100%
9
AVI
0–10 V = 0–100%
10
ACI
4–20 mA = 0–100%
12
Iq current command
(2.5 × drive rated current) is processed as 100%.
13
Iq feedback value
(2.5 × drive rated current) is processed as 100%.
14
Id current command
(2.5 × drive rated current) is processed as 100%.
15
Id feedback value
(2.5 × rated current) is processed as 100%.
16
Vq-axis voltage command
230 V models: 250 V = 100%
460 V models: 500 V = 100%
575 V models: 625 V = 100%
17
Vd-axis voltage command
230 V models: 250 V = 100%
460 V models: 500 V = 100%
575 V models: 625 V = 100%
18
Torque command
Motor rated torque = 100%
19
PG2 frequency command
Maximum operation frequency (Pr.01-00) is processed as
100%.
20
CANopen analog output
For CANopen communication analog output
Terminal
Address
AFM
2026-A1
21
RS-485 analog output
For RS-485 (Modbus) control analog output
Terminal
Address
AFM
26A0H
22
Communication card analog
output
For communication analog output
(CMM-EIP01, CMM-PN01, CMM-DN01)
Terminal
Address
AFM
26A0H
23
Constant voltage output
Pr.03-32 controls the voltage output level.
0–100% of Pr.03-32 corresponds to 0–10 V for AFM.
