Delta VFD2A8MS21ANSAA User Manual

Chapter 12 Descriptions of Parameter SettingsMS300
448
Pr.
Parameter Name
Settings
00-21
Operation command source
(AUTO, REMOTE)
1 (External terminals)
01-00
Motor 1 maximum operation frequency
Default setting
01-12
Acceleration time 1
3 (sec.)
01-13
Deceleration time 1
3 (sec.)
03-00
Analog input selection (AVI)
5 (PID feedback signal)
03-50
Analog input curve selection
1: Three-point curve of AVI
03-63
AVI voltage lowest point
0.00
03-65
AVI voltage mid-point
9.99
03-66
AVI proportional mid-point
100%
08-00
Terminal selection of PID feedback
1: Negative PID feedback: by analog input
(Pr.03-00, Pr.03-01)
08-01
Proportional gain (P)
10
08-02
Integral time (I)
1
08-20
PID mode selection
1: Parallel connection
08-21
Enable PID to change the operation
direction
0: Operation direction cannot be changed
08-65
PID target value source
1: Pr.08-66 setting
08-66
PID target value setting
50%
 Setting 12: Tension PID + master / auxiliary frequency
The following table lists the relevant tension PID + master / auxiliary frequency setting
application parameters.
Pr.
Parameter Name
Settings
00-20
Master frequency command source
(AUTO, REMOTE)
9 (PID controller)
00-21
Operation command source
(AUTO, REMOTE)
1 (External terminals)
01-00
Motor 1 maximum operation frequency
Default setting
01-12
Acceleration time 1
3 (sec.)
01-13
Deceleration time 1
3 (sec.)
00-35
Auxiliary frequency source
3: Analog input
03-00
Analog input selection (AVI)
5 (PID feedback signal)
03-01
Analog input selection (ACI)
12: Auxiliary frequency input
03-10
Reverse setting when analog signal input
is negative frequency
0: Negative frequency input is not allowed.
The digital keypad or external terminal
controls the forward and reverse
direction.
03-12
Analog input gain (ACI)
100.0%
03-29
ACI terminal input selection
1: 0–10 V
