Loading...How to troubleshoot OFF POWER LED on Delta VFD2A8MS21ANSAA DC Drives?
If the POWER LED is off, it indicates no power. Check if the connection between the CMM-PD02 and the AC motor drive is normal.
What to do if the Delta DC Drives NET LED flashes orange?
If the NET LED flashes orange, it means that the CMM-PD02 fails to communicate with the AC motor drive. To solve this, switch off the power and check whether the CMM- PD02 is correctly installed and normally connected to the AC motor drive.
Why is the NET LED on my Delta DC Drives red?
A red light on the NET LED indicates that the CMM-PD02 is not connected to the PROFIBUS DP bus. To resolve this, connect the CMM-PD02 to the PROFIBUS DP bus.
What to do if the Delta DC Drives NET LED flashes red?
If the NET LED flashes red, it signifies an invalid PROFIBUS communication address. To fix this, set the PROFIBUS address of the CMM-PD02 between 1–125 (decimal).
General| Protection Level | IP20 |
|---|---|
| Control Method | V/F Control, Sensorless Vector Control |
| Frequency Range | 0.1-400Hz |
| Protection Features | Over-voltage, Over-current, Overload, Overheat, Low-voltage, Ground Fault, Short Circuit |
| Cooling Method | Fan Cooling |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -20°C to 60°C |
| Altitude | 1000m |
Key safety regulations and correct/incorrect methods for grounding the motor drive and equipment.
Specifies minimum required clearances (A, B, C) for single drive, side-by-side, and zero stack installations based on ambient temperature.
Provides airflow rates and power dissipation values for various AC motor drives across different frames (A, B, C, D, E, F).
Illustrates the system wiring diagram for power input, NFB/fuse, electromagnetic contactor, AC/DC reactors, and EMC filter.
Details on input wiring for single-phase/three-phase power and wiring precautions for power and control terminals.
Provides a diagram of the main circuit terminals including R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, DC-/DC+/+1, +2/B1, B2, and ground connection.
Details wiring specifications for Relay and Control terminals, including stripping length, wire gauge, and tightening torque.
Lists brake resistors and brake units suitable for AC motor drives, including part numbers, specifications, and torque values.
Describes the KPC-CC01 digital keypad, its communication interface, protocol, installation method, and function descriptions.
Details the operational processes for the keypad, including main page selection, setting parameters, shifting data, and PLC settings.
Details protection parameters including low voltage level, over-voltage stall prevention, over-current stall prevention, and over-torque detection.
Summarizes communication parameters such as address, transmission speed, fault treatment, time-out detection, protocol, and block transfers.
Lists protection parameters for output frequency, DC bus voltage, output current, and IGBT temperature malfunctions.
Lists all warning codes with their ID, display on LCD, name, description, and recommended error resolution.
Provides a comprehensive list of fault codes, including ID, display on LCD, fault name, fault descriptions, and corrective actions.
Provides instructions for CANopen wiring using an external communication card CMM-COP01 and RJ45 cable with terminating resistors.
Provides wiring diagrams for the safe control loop, including internal circuit and STO wiring.
Explains error codes related to STO/STL functions and provides troubleshooting instructions based on keypad display.
