Appendix A. Modbus ProtocolMS300
791
Function Name
Modbus
Address
Attribute
(Function
Code)
Size
Description
Multi-step speed
status
2107H
R(03H)
U16
Drive’s current running speed step given by multi-step speed
command (0 is main speed)
Counter value
2109H
R(03H)
The present value of MI
Output power factor
angle
210AH
R(03H)
Drive’s output power factor angle (XXX.X°) (0.0–180.0°)
Output torque
210BH
R(03H)
Output torque (XXX.X %)
Motor actual speed
210CH
R(03H)
Actual motor speed (XXXXX rpm)
Number of PG
feedback pulses
210DH
R(03H)
Number of PG feedback pulses (0~65535)
Number of pulse
commands
210EH
R(03H)
Number of PG2 pulse commands (0~65535)
Power output
210FH
R(03H)
Drive’s output power (X.XXX kW)
Multi-function display
2116H
R(03H)
Display the low word value (Pr.00-04) of user-defined items,
the value is low 16 bits data.
Maximum user-
defined value
211BH
R(03H)
Maximum Operation Frequency (Pr.01-00) or Maximum
User-defined Value (Pr.00-26)
 When Pr.00-26 is 0, this value is equal to Pr.01-00
setting
 When Pr.00-26 is not 0, and the command source is
keypad, this value = Pr.00-24 × Pr.00-26 / Pr.01-00
 When Pr.00-26 is not 0, and the command source is
485, this value = Pr.09-10 × Pr.00-26 / Pr.01-00
Output current digit
211FH
R(03H)
High byte: Current digit (display)
