Chapter 8 Option CardsC2000 Plus
8-46
Parameters Functions Current Setting Value Descriptions
09-77 IP address -2 168 IP address 192.168.1.5
09-78 IP address -3 1 IP address 192.168.1.5
09-79 IP address -4 5 IP address 192.168.1.5
09-80 Netmask -1 255 Netmask 255.255.255.0
09-81 Netmask -2 255 Netmask 255.255.255.0
09-82 Netmask -3 255 Netmask 255.255.255.0
09-83 Netmask -4 0 Netmask 255.255.255.0
09-84 Default gateway -1 192 Default gateway 192.168.1.1
09-85 Default gateway -2 168 Default gateway 192.168.1.1
09-86 Default gateway -3 1 Default gateway 192.168.1.1
09-87 Default gateway -4 1 Default gateway 192.168.1.1
8-15-6 LED Indicator & Troubleshooting
There are two LED indicators on the CMC-EIP01. The POWER LED displays the status of power
supply, and the LINK LED displays the connection status of the communication.
LED Indicators
LED Status Indication Corrective Action
POWER Green
ON Power supply in normal status --
OFF No power supply
Check the power supply.
LINK Green
ON
Network connection in normal
status
--
Flashes Network in operation
--
OFF Network not connected
Check if the network cable is
connected.
Troubleshooting
Abnormality Cause Corrective Action
POWER LED OFF
The AC motor drive not
powered
Check the power of the AC motor drive, and see if the
power supply is normal.
The CMC-EIP01 not
connected to the AC motor
drive
Ensure that CMC-EIP01 is connected to the AC
motor drive.
LINK LED OFF
The CMC-EIP01 not
connected to network
Ensure that the network cable is correctly connected
to network.
Poor contact to RJ45
connector
Ensure that RJ45 connector is connected to Ethernet
port.
Cannot find
communication card
The CMC-EIP01 not
connected to network
Ensure that CMC-EIP01 is connected to network.
The PC and CMC-EIP01 in
different networks and
blocked by network firewall.
Search by IP or set up relevant settings by the AC
motor drive keypad.
Cannot open CMC-
EIP01 setup page
The CMC-EIP01 not
connected to network
Ensure that CMC-EIP01 is connected to the network.
Incorrect communication
setting in DCISoft
Ensure that the communication setting in DCISoft is
set to Ethernet.
