Delta VFD450C43S-21 User Manual

Chapter 5 Main Circuit TerminalsC2000 Plus
5-16
Frame G
R/L11 T/L31 U/T1 V/T2T/L32R/L12 W/T3S/L21
+1/DC
S/L22 -/DC-
 If you install at Ta 40°C (for 460V model names with last digit -21; for 690V model names end with 63B-21) /
50°C (for 460V model names with last digit -00; for 690V model names end with 63B-00) environment, use
copper wires have a voltage rating of 600V and are temperature resistance to 75°C or 90°C.
 If you install at Ta 40°C (for 460V model names with last digit -21; for 690V model names end with 63B-21) /
50°C (for 460V model names with last digit -00; for 690V model names end with 63B-00) above environment,
use copper wires have a voltage rating of 600V and are temperature resistant ntance to 90°C or above.
 For VFD2200C43A-00, VFD2500C43A-00 ( main circuit terminals U/T1, V/T2, W/T3, －/DC-, ＋/DC+ )
models: if you install at Ta 45°C above environment, use copper wires that have a voltage rating of 600V and
are temperature resistance to 90°C or above.
 To be UL installation compliant, you must use copper wires when installing. The wire gauge is based on
temperature resistance of 75°C, in accordance with UL requirements and recommendations. Do not reduce
the wire gauge when using high-temperature resistant wire.
Model Name
Main Circuit Terminals
R/L11、R/L12、S/L21、S/L22、T/L31、T/L32
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
Max. Wire Gauge Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
VFD1850C43A-00
120 mm
2
*4
(250MCM*4)
70 mm
2
*4 (2/0 AWG*4)
M8
180 kg-cm
(156.2
lb-in.)
(17.65 Nm)
70 mm
2
*4 (2/0AWG*4) 70 mm
2
*2 (2/0 AWG*2)
M8
180 kg-cm
(156.2 lb-in.)
(17.65 Nm)
VFD2000C43A-00 70 mm
2
*4 (2/0 AWG*4) 70 mm
2
*4 (2/0AWG*4) 70 mm
2
*2 (2/0 AWG*2)
VFD2200C43A-00 70 mm
2
*4 (2/0 AWG*4) 70 mm
2
*4 (2/0AWG*4) 70 mm
2
*2 (2/0 AWG*2)
VFD2500C43A-00 95 mm
2
*4 (3/0 AWG*4) 95 mm
2
*4 (3/0AWG*4) 95 mm
2
*2 (3/0 AWG*2)
VFD1850C43A-21 50 mm
2
*4 (1/0 AWG*4) 50 mm
2
*4 (1/0AWG*4) 50 mm
2
*2 (1/0 AWG*2)
VFD2000C43A-21 50 mm
2
*4 (1/0 AWG*4) 50 mm
2
*4 (1/0AWG*4) 50 mm
2
*2 (1/0 AWG*2)
VFD2200C43A-21 50 mm
2
*4 (1/0 AWG*4) 50 mm
2
*4 (1/0AWG*4) 50 mm
2
*2 (1/0 AWG*2)
VFD2500C43A-21 70 mm
2
*4 (2/0 AWG*4) 70 mm
2
*4 (2/0AWG*4) 70 mm
2
*2 (2/0 AWG*2)
VFD2500C63B-00
150mm
2
*4
(300MCM*4)
50 mm
2
*4 (1/0 AWG*4) 50 mm
2*
4 (1/0 AWG*4) 50 mm
2*
2 (1/0 AWG*2)
VFD3150C63B-00 50 mm
2
*4 (1/0 AWG*4) 50 mm
2*
4 (1/0 AWG*4) 50 mm
2*
2 (1/0 AWG*2)
VFD2500C63B-21 50 mm
2
*4 (1/0 AWG*4) 50 mm
2*
4 (1/0 AWG*4) 50 mm
2*
2 (1/0 AWG*2)
VFD3150C63B-21 50 mm
2
*4 (1/0 AWG*4) 50 mm
2*
4 (1/0 AWG*4) 50 mm
2*
2 (1/0 AWG*2)
