Chapter 11 Summary of Parameter SettingsME300
11-24
Pr. Explanation Settings Default
33: U-phase current detection error (cd1)
34: V-phase current detection error (cd2)
35: W-phase current detection error (cd3)
36: Clamp current detection error (Hd0)
37: Over-current detection error (Hd1)
40: Auto-tuning error (AUE)
41: PID feedback loss (AFE)
48: Analog current input loss (ACE)
49: External fault input (EF)
50: Emergency stop (EF1)
51: External Base Block (B.B.)
52: Password error (Pcod)
54: Communication error (CE1)
55: Communication error (CE2)
56: Communication error (CE3)
57: Communication error (CE4)
58: Communication time-out (CE10)
61: Y-connection /Δ-connection switch error (ydc)
62: Deceleration energy backup error (dEb)
72: Channel 1 (S1–DCM) safety loop error (STL1)
76: Safe Torque Off (STo)
77: Channel 2 (S2–DCM) safety loop error (STL2)
78: Internal loop error (STL3)
79: U-phase over-current before run (Uoc)
80: V-phase over-current before run (Voc)
81: W-phase over-current before run (Woc)
82: U-phase output phase loss (OPHL)
83: V-phase output phase loss (OPHL)
84: W phase output phase loss (OPHL)
87: Drive overload in low frequency (oL3)
89: Initial rotor position detection error (RoPd)
140: GFF detected when power on (Hd6)
141: GFF before run (BGFF)
142: Auto-tuning error 1 (DC test stage) (AUE1)
143: Auto-tuning error 2 (High frequency test stage)
(AUE2)
144: Auto-tuning error 3 (Rotary test stage) (AUE3)
06-23 Fault output option 1 0–65535 (refer to bit table for fault code) 0
06-24 Fault output option 2 0–65535 (refer to bit table for fault code) 0
06-25 Fault output option 3 0–65535 (refer to bit table for fault code) 0
