Chapter 12 Description of Parameter SettingsME300
12.1-09-9
Content Register Function
bit 14–13 00B: No function
01B: Operated by digital keypad
10B: Operated by Pr.00-21 setting
11B: Change operation source
bit 15 Reserved
2001H Frequency command (XXX.XX Hz)
2002H bit 0 1: EF (external fault) on
bit 1 1: Reset
bit 2 1: B.B. ON
bit 15–3 Reserved
Status monitor read
only
2100H
High byte: Warn code
Low Byte: Error code
2101H
bit 1–0
AC motor drive operation status
00B: Drive stops
01B: Drive decelerating
10B: Drive standby
11B: Drive operating
bit 2 1: JOG command
bit 4–3
Operation direction
00B: FWD run
01B: From REV run to FWD run
10B: REV run
11B: From FWD run to REV run
bit 8
1: Master frequency controlled by communication
interface
bit 9 1: Master frequency controlled by analog signal
bit 10
1: Operation command controlled by
communication interface
bit 11 1: Parameter locked
bit 12 1: Enable to copy parameters from keypad
bit 15–13 Reserved
2102H Frequency command (XXX.XX Hz)
2103H Output frequency (XXX.XX Hz)
2104H
Output current (XX.XX A). When current is higher than 655.35,
it shifts the decimal as (XXX.X A). The decimal can refer to
High byte of 211F.
2105H DC BUS voltage (XXX.X V)
2106H Output voltage (XXX.X V)
2107H Current step number of multi-step speed operation
2108H Reserved
2109H Counter value
210AH Power factor angle (XXX.X)
210BH Output torque (XXX.X %)
210CH Motor speed (XXXXX rpm)
210FH Prompt Power output (X.XXX kW)
2116H Multi-function display (Pr.00-04)
211BH
Maximum Operation Frequency (Pr.01-00) or Maximum
User-defined Value (Pr.00-26)
When Pr.00-26 is 0, this value is equal to Pr.01-00 setting.
When Pr.00-26 is not 0, and the command source is keypad,
this value = Pr.00-24 * Pr.00-26 / Pr.01-00.
When Pr.00-26 is not 0, and the command source is 485, this
value = Pr.09-10 * Pr.00-26 / Pr.01-00.
211FH High byte: decimal of current value (display)
2157H Display the position of multi-point positioning
