Delta VFD4A2ME43ANNAA User Manual

Chapter 13 Warning CodesME300
13-4
Cause Corrective Actions
Check if the ambient temperature
or temperature inside the cabinet
is too high, or if there is obstruction
in the ventilation hole of the control
cabinet.
1. Check the ambient temperature.
2. Regularly inspect the ventilation hole of the control cabinet.
3. Change the installed place if there are heating objects, such as braking
resistors, in the surroundings.
4. Install/ add cooling fan or air conditioner to lower the temperature inside the
cabinet.
Check if there is any obstruction on
the heat sink or if the fan is
running.
Remove the obstruction or replace the cooling fan.
Insufficient ventilation space Increase ventilation space of the drive.
Check if the drive matches the
corresponded loading.
1. Decrease the loading.
2. Decrease the carrier.
3. Replace with a drive with larger capacity.
The drive has run 100% or more
than 100% of the rated output for a
long time.
Replace with a drive with larger capacity.
ID No. Display on LCM Keypad Warning Name Description
11
PID feedback error
(PID)
PID feedback loss (warning for analog feedback signal;
works only when PID enables)
Action and Reset
Action level When the analog input is lower than 4 mA (only detects analog input 4–20 mA).
Action time Pr.08-08
Warning treatment parameter
Pr.08-09
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: Warn and operate at last frequency
Reset method
Auto
“Warning” occurs when Pr.08-09=0 or 3. The “Warning” automatically
clears when the feedback signal is larger than 4 mA.
Manual “Error” occurs when Pr.08-09=1 or 2. You must reset manually.
Reset condition Immediately reset
Record
Records when Pr.08-09=1 or 2 (“Error”).
Does not record when Pr.08-09=0 or 3 (“Warning”).
Cause Corrective Actions
Loose or broken PID feedback
wiring
Tighten the terminals again.
Replace with a new cable.
Feedback device malfunction Replace with a new feedback device.
Hardware error
If the PID error still occurs after checking all the wiring, send the drive back to
the factory for repair.
ID No. Display on LCM Keypad Warning Name Description
12
ACI analog signal loss
(AnL)
Analog input current loss (including all analog 4–20 mA
signals)
Action and Reset
Action level When the analog input is lower than 4 mA (only detects analog input 4–20 mA)
Action time Immediately act
Warning treatment parameter
Pr.03-19
0: Disable
1: Continue operation at the last frequency (warning, the keypad displays ”ANL”)
2: Decelerate to 0 Hz (warning, the keypad displays ”ANL”)
3: Stop immediately and display “ACE”
Reset method
Auto
“Warning” occurs when Pr.03-19=1 or 2. The “Warning automatically
clears when the analog input signal is larger than 4 mA.
Manual “Error” occurs when Pr.03-19=3. You must reset manually.
Reset condition Immediately reset
Record Does not record when Pr.03-19=1 or 2 (“Warning”).
Cause Corrective Actions
Loose or broken ACI wiring
Tighten the terminals again.
Replace with a new cable.
