Delta VFD4A2ME43ANNAA User Manual

Chapter 7 Optional AccessoriesME300
7-18
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Intput /
Output AC
Reactor
[mH]
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
[mH]
DC reactor
Delta part #
VFD4A8ME23ANNAA
VFD4A8ME23ANSAA
5 7.5 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD7A5ME23ANNAA
VFD7A5ME23ANSAA
8 12 1.585 DR008A0159 DR008L0159 3.66 DR008D0366
VFD11AME23ANNAA
VFD11AME23ANSAA
12.5 18.75 0.746 DR017AP746 DR017LP746 2.662 DR011D0266
VFD17AME23ANNAA
VFD17AME23ANSAA
19.5 29.25 0.507 DR025AP507 DR025LP507 1.722 DR017D0172
VFD25AME23ANNAA
VFD25AME23ANSAA
27 40.5 0.32 DR033AP320 DR033LP320 1.172 DR025D0117
230V, 50–60 Hz / Three-Phase - Heavy Duty
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Intput /
Output AC
Reactor
[mH]
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
[mH]
DC reactor
Delta part #
VFD0A8ME23ANNAA
VFD0A8ME23ANSAA
0.8 1.6 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD1A6ME23ANNAA
VFD1A6ME23ANSAA
1.6 3.2 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD2A8ME23ANNAA
VFD2A8ME23ANSAA
2.8 5.6 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD4A8ME23ANNAA
VFD4A8ME23ANSAA
4.8 9.6 2.536 DR005A0254 DR005L0254 5.857 DR005D0585
VFD7A5ME23ANNAA
VFD7A5ME23ANSAA
7.5 15 1.585 DR008A0159 DR008L0159 3.66 DR008D0366
VFD11AME23ANNAA
VFD11AME23ANSAA
11 22 1.152 DR011A0115 DR011L0115 2.662 DR011D0266
VFD17AME23ANNAA
VFD17AME23ANSAA
17 34 0.746 DR017AP746 DR017LP746 1.722 DR017D0172
VFD25AME23ANNAA
VFD25AME23ANSAA
25 50 0.507 DR025AP507 DR025LP507 1.172 DR025D0117
460V, 50–60 Hz / Three-Phase - Normal Duty
Model
Rated
Current
[Arms]
Saturation
Current
[Arms]
Intput /
Output AC
Reactor
[mH]
Intput AC
reactor
Delta part #
Outtput AC
reactor
Delta part #
DC
Reactor
[mH]
DC reactor
Delta part #
VFD1A5ME43ANNAA
VFD1A5ME43AFNAA
VFD1A5ME43ANSAA
VFD1A5ME43AFSAA
1.8 2.7 8.102 DR003A0810 DR003L0810 18.709 DR003D1870
VFD2A7ME43ANNAA
VFD2A7ME43AFNAA
VFD2A7ME43ANSAA
VFD2A7ME43AFSAA
3 4.5 6.077 DR004A0607 DR004L0607 18.709 DR003D1870
VFD4A2ME43ANNAA
VFD4A2ME43AFNAA
VFD4A2ME43ANSAA
VFD4A2ME43AFSAA
4.6 6.9 4.05 DR006A0405 DR006L0405 14.031 DR004D1403
VFD5A5ME43ANNAA
VFD5A5ME43AFNAA
VFD5A5ME43ANSAA
VFD5A5ME43AFSAA
6.5 9.75 2.7 DR009A0270 DR009L0270 9.355 DR006D0935

Delta VFD4A2ME43ANNAA Specifications
