Chapter 3 Installation MS300
3-5
Frame
Airflow Rate for Cooling Power Dissipation for AC Motor Drive
Model No.
Flow Rate
(Unit: cfm)
Flow Rate
(Unit: m
3
/ hr)
Loss External
(Heat sink, unit: W)
Internal
(Unit: W)
Total
(Unit: W)
C
VFD5A5MS43ANSAA
VFD5A5MS43ENSAA
VFD5A5MS43AFSAA
16.0 27.2
60.6 22.8 83.4
VFD7A3MS43ANSAA
VFD7A3MS43ENSAA
VFD7A3MS43AFSAA
75.2 30 105.2
VFD9A0MS43ANSAA
VFD9A0MS43ENSAA
VFD9A0MS43AFSAA
93.1 42 135.1
VFD4A2MS53ANSAA 46.6 22.2 68.8
VFD6A6MS53ANSAA 76.1 30 106.1
D
VFD25AMS23ANSAA
VFD25AMS23ENSAA
23.4 39.7
192.8 53.3 246.1
VFD13AMS43ANSAA
VFD13AMS43ENSAA
VFD13AMS43AFSAA
132.8 39.5 172.3
VFD17AMS43ANSAA
VFD17AMS43ENSAA
VFD17AMS43AFSAA
164.7 55.8 220.5
VFD9A9MS53ANSAA 93.9 37 130.9
VFD12AMS53ANSAA 108.4 51 159.4
E
VFD33AMS23ANSAA
VFD33AMS23ENSAA
53.7 91.2
244.5 79.6 324.1
VFD49AMS23ANSAA
VFD49AMS23ENSAA
374.2 86.2 460.4
VFD25AMS43ANSAA
VFD25AMS43ENSAA
VFD25AMS43AFSAA
234.5 69.8 304.3
VFD32AMS43ANSAA
VFD32AMS43ENSAA
VFD32AMS43AFSAA
319.8 74.3 394.1
F
VFD65AMS23ANSAA
VFD65AMS23ENSAA
67.9 115.2
492.0 198.2 690.2
VFD38AMS43ANSAA
VFD38AMS43ENSAA
VFD38AMS43AFSAA
423.5 181.6 605.1
VFD45AMS43ANSAA
VFD45AMS43ENSAA
VFD45AMS43AFSAA
501.1 200.3 701.4
Table 3-2
