Chapter 5 Methods of Anomaly Diagnosis | VFD-VJ
5-15
5-1-3 Warning Codes
No.
Display
Fault codes defined
by Delta
(2021H High Byte)
Descriptions
A1

0001H
Modbus function code error (Illegal function code) (CE1)
Corrective Actions
 Check if the function code is correct.
(Function code must be 03, 06, 10, 63)
A2

0002H
Modbus data address is error (Illegal data address (00 H to
254 H) (CE2)
Corrective Actions
 Check if the communication address is correct.
A3

0003H
Modbus data error (Illegal data value) (CE3)
Corrective Actions
 Check if the data value exceeds maximum / minimum
value.
A4

0004H
Modbus communication error (Data is written to read-only
address) (CE4)
Corrective Actions
 Check if the communication address is correct.
A5

0005H Modbus transmission time-out (CE10)
A6

0006H Keypad transmission time-out (CP10)
A7

0007H
Keypad COPY error 1 (SE1)
Keypad simulation error, including communication delays,
communication error (keypad receives error FF86) and
parameter value error.
A8

0008H
Keypad COPY error 2 (SE2)
Keypad simulation done, parameter writes error.
A9

0009H
IGBT is over-heated than protection level: 95
o
C (oH1)
Corrective Actions
 Ensure that the ambient temperature falls within the
specified temperature range.
 Make sure that the ventilation holes are not obstructed.
 Remove any foreign objects from the heat sink and check
for possible dirt in heat sink.
 Provide enough spacing for adequate ventilation.
