Delta VFD550VL43C-J User Manual

Appendix B: CANopen Overview | VFD-VJ
Apx B - 15
Index Sub Definition
Factory
Setting
R/W Size Note
to run forward
10B
: Switch from run forward
to run in reverse
11B: Run in reverse
Bit 7–5 Reserved
Bit 8
1
: Master Frequency command
controlled by communication
interface
Bit 9
1
: Master Frequency
command controlled by
analog / external terminal
signal input
Bit 10
1
: Operation command
controlled by communication
interface
Bit 11 1: Parameter lock
Bit 12 Reserved
Bit 15–13
Reserved
3
Frequency command
(XXX.XXHz)
0 R U16
4 Output freq. (XXX.XX Hz) 0 R U16
5 Output current (XXX.XX A) 0 R U16
6 DC BUS voltage (XXX.X V) 0 R U16
7 Output voltage (XXX.X V) 0 R U16
8
Reserved
0 R U16
9 Reserved 0 R U16
A Reserved 0 R U16
B Reserved 0 R U16
C Reserved 0 R U16
D Reserved 0 R U16
E Reserved 0 R U16
F Reserved 0 R U16
10 Reserved 0 R U16
17
Multi-function display
(Pr.00-04)
0 R U16
2022H 0 Reserved 0 R U16
1
Display output current
(XX.XXA)
0 R U16
2 Display counter value 0 R U16
3
Display actual output
frequency(XXX.XX Hz)
0 R U16
4
Display DC-BUS voltage
(XXX.X V)
0 R U16
5
Display output voltage
(XXX.X V)
0 R U16
6
Display output power angle
(XXX.X°)
0 R U16
7
Display output power by U,
V, W in kW (XX.XXX kW)
0 R U16
8
Display actual motor speed
(XXXXX rpm)
0 R U16
9
Display estimate output
torque (XXX.X%)
0 R U16
A Display PG feedback 0 R U16
B
Reserved
0 R U16
C
Display signal for PS analog
0 R U16
