7
WARNING
IF THE BATTERY REMAINS INSTALLED IN THE VEHICLE:
1. DO NOT CONNECT THE CHARGER’S OUTPUT LEADS TO THE SOLAR
PANEL UNTIL ALL OTHER CONNECTIONS ARE MADE!
2. Place and OUTPUT DC power cords in the best position to avoid accidental
damage by movable vehicle parts, i.e. hoods, doors, or moving engine parts
(fan blades, belts, or pulleys).
3. Check the polarity of the battery posts. If the positive (pos, p, +) post is
connected to the vehicle chassis, then the vehicle has a positive ground
system. If the negative (neg, n, -) post is connected to the vehicle chassis,
then the vehicle has a negative ground system. Negative ground systems are
the most common.
4. For negative ground systems, connect the positive (red) alligator clip, or ring
terminal to the positive battery post. Then connect the negative (black)
alligator clip, or ring terminal to the vehicle chassis. Do not make the negative
charger clip or ring connection to the carburetor, fuel lines, or thin, sheet metal
parts. Make that connection to the engine block or a heavy gauge metal part
of the frame.
5. For positive ground systems, connect the negative (black) alligator clip, or ring
terminal to the negative battery post. Then connect the positive (red) alligator
clip, or ring terminal to the vehicle chassis. Do not make the positive charger
clip or ring connection to the carburetor, fuel lines, or thin, sheet metal parts.
Make that connection to the engine block or a heavy gauge metal part of the
frame.
8
PRODUCT SPECIFICATIONS
SOLAR CONTROLLER
Input Sunlight
Output 15.2VDC, 325mA (5Watt)
Part Number 021-1171
Working Temperature -49 to185°F (- 45 to 85°C)
Warranty 5 years
Certification IP67 Rated
PRODUCT OVERVIEW
Below is a list of items that should be included in your retail box:
1) 1 - Solar Panel
2) 4 - Suction Cups
3) 4 - 5mm Hex Nuts
4) 1 - Male Cigarette Adapter with 18” cord
5) 1 - Instruction Manual
