DEMA D5M Series User Manual

NO.5 Function List
18
31: Actuation indication of
electromagnetic relay
32: Fan actuation indication
P054
AO output function
Analog voltage output 0-3
0
○
P055
AO analog output gain
0-100%
100
○
P056
Hopping frequency 1
0.00-400.00Hz
0.00
○
P057
Hopping frequency 2
0.00-400.00Hz
0.00
○
P058
Hopping frequency 3
0.00-400.00Hz
0.00
○
P059
Range of hopping
frequency
0.10-10.00 Hz
0.50
○
P060
Frequency consistency I
0.00-400.00 Hz
0.00
○
P061
Frequency consistency II
0.00-400.00 Hz
0.00
○
P062
Frequency
consistency range setting
0.10-10.00 Hz
0.50
○
P063
Timer I
0.1-10.0s
0.1
╳
P064
Timer II
1-100s
1
╳
P065
Count value
0-65500
0
○
P066
Value of middle counter
0-65500
0
○
P067
Digital input terminal
Positive and negative logic
0: Positive logic, wiring mode
NPN
1: Negative logic, wiring mode
PNP
01
╳
P068-P069
Reserve
5.4 Functional parameters of analog quantity
Function
code
Function name
Setting range and data content
Ex-factory
value
Alteration
P070
Input channel selection
for analog quantity
0: 0-10V 1: 0-5V
2: 0-20mA 3: 4-20mA
4: Overlaying of 0-10V/4-20mA
0
╳
P071
Filtering constant of
analog quantity
0-50
20
╳
P072
High-end frequency of
analog frequency
0.00-400.00 Hz
50.00
╳
P073
Low-end frequency of
analog quantity
0.00-400.00 Hz
0
╳
P074
Bias direction of
high-end frequency
0: Positive
1: Negative
0
╳
