10
211 338 44.indd / 081019
Part no.
DRC-MJ D3 hand-held transmitter 773 760 44
Contents of the complete delivery:
• 1 DRC-MJ D3 hand-held transmitter
• 1 rechargeable battery pack 2,4 V/ReCyKo/2050 mAh 773 499 44
• 1 plug-in charger (rechargeable battery) 110 – 230 V 50/60 Hz 773 438 44
• 1 DRC-MJ D3 hand-held transmitter user manual/assy. instructions 211 338 44
• 1 set of button symbols for DRC-MJ D3 hand-held transmitter 773 465 44
DRC-DR D3 radio receiver 711 333 45
Aerial for DRC-DR D3 receiver for (DR/DMR) 711 445 45
DRC-MP D3 radio receiver 24 V AC/DC – 240 V AC 90/60 Hz 773 794 44
Spare carrying strap, length approx. 22 cm 773 425 33
External charger 773 501 44
To charge a battery pack (773 499 44)
Connection to 230 V supply by multi-norm connector
2,5 hours for full charge, automatic trickle charging
Spare parts set for DRC-MJ D3 hand-held transmitter 773 415 33
Contents:
1 x upper housing cap,
1 x lower housing cap
5 x bridge contacts
Wall bracket 773 688 44
Fixed storage position for DRC hand-held transmitters. Rugged metal design. A
hand-held transmitter can be placed in it with a plug-in charger connected to it.
Coding labels Black background foil 895 639 44
Coding labels 7 segments (yellow) 895 640 44
Large cross-travel direction foil (dimensions: 500 x 200 mm) 895 635 44
Large long-travel direction foil (dimensions: 500 x 200 mm) 895 637 44
Small cross-travel direction foil (dimensions: 100 x 250 mm) 851 525 44
Small long-travel direction foil (dimensions: 100 x 250 mm) 851 526 44
DRC-MJ D3 hand-held transmitters are sealed in the factory.
DRC-MJ D3 hand-held transmitters may only be opened for repair purposes by
authorised parties.
3 Device selection
NOTE
Breaking a casing seal such as this will result in the loss of all warranty rights.
i
3.1 DRC-MJ scope of
delivery
3.2 Available radio
receivers
3.3 Accessories for
DRC-MJ hand-held
transmitters
3.4 Accessories for crane
identification
3.5 Casing seal/seal
breakage
