Demco Gravity Flow 550 - Safety Sign Locations

Page 8
SAFETY SIGN LOCATIONS
Types of safety sign and locations on equipment are shown in illustration below. Good safety requires that you familiarize
yourself with various safety signs, type of warning, and area or particular function related to that area, that requires your
SAFETY AWARENESS.
J
J
H
G
F
I
D
C
B
A
C
H
I
E
H
C
Please order replacement parts by PART NO. and DESCRIPTION.
A AG21173 550 (Charcoal)
AG21174 650 (Charcoal)
AG21175 750 (Charcoal)
B AG21067 Keep Off Ladder
C 04508 Amber Reflector
D AG21006 Wagon Safety
E AG21192 Left Stripe (Charcoal)
AG21193 Right Stripe (Charcoal)
F AG21070 Attention Do Not Turn Sharply
G AG21002 Caution 20 M.P.H.
CAUTION!
Do not exceed 20 MPH
when loaded.
09/99 AG21002
G
D
M
F
K
K
K
B
L
H 04804 Red Reflector
I AG21163 Large Demco (Charcoal)
J 07278 Conspicuity (w/ White to the Top)
K AG21127 Check All Wheel Nuts
L BH21003 Brake Lever Indicator, Red/Green
M AG21001 Tire Pressure and Torque Rating
A
I
H
NOTICE!
Keep wheel lug nuts or bolts tightened to specified torque
IMPORTANT :
Always retorque wheels after first trip!
CAUTION:
Over inflation may result in damage to
running gear and box integrity.
REV 5 AG21001
650/750bu.
3/4”-16UNF Grade 8
T o rque to 400 ft. lbs.
450/550bu.
5/8”-18UNF Grade 8
T o rque to 225 ft. lbs.
Check tire pressure regularly .
365bu.
5/8”-18UNF Grade 5
T o rque to 150 ft. lbs.
Nut or Bolt T o rques
Tire Pressure for all 365/450/550/650/750
Bushel Gravity Flow W a gons
60 psi.
