9
Cut-Bag Switch Position
To cut and seal a side of a bag, place the
selector in the Cut-Bag position (Figure 8).
When the switch is in the Cut-Bag position,
and the lid is pressed down fully, the middle
(exposed) wire of the heat-sealing element is
activated. This wire then cuts one side of the bag.
SPECIAL FEATURES OF THE
FRESHLOCK TURBO II
Patented MultiSeal™ Three-Wire
Heat-Sealing System
The patented heat-sealing mechanism has
three wires (Figure 7). The outer (covered) wire
seals the first side of the next bag to be made
from the roll. The center (exposed) wire cuts both
the side of the bag being made and the first side
of the next bag to be made from the roll. The cen-
ter wire also forms an extra-protection MultiSeal
for each bag.
The two covered wires seal the bags.
The exposed wire cuts the bag.
FIGURE 7 FIGURE 8
CUT-BAG SWITCH
POSITION
1830 Instructions 7/16/03 3:39 PM Page 9
