smartDEN IP-16R-XX User Manual

13 Apr 2021

-3-

1. Features

smartDEN IP-16R-XX is a LAN relay module with 16 SPDT relays for remote

control with integrated web server for set-up, API integration protocol (depending on

the model) and http/xml/json support for embedding in other systems. The built-in

real time clock allows organizing schedule stand-alone work without connection to

computer. The module is able to act like network watch-dog in order to monitor and

reboot network equipment automatically.

 10 Mb Ethernet interface with Link/Activity Led;

 Auto-MDIX;

 16 SPDT relays (with NO and NC contacts);

 Led for each relay;

 Pulse function (timer) for every relay;

 Real Time Clock (RTC) for schedule (calendar) stand-alone work;

 Web server with secure login authorization;

 Secure HTTP/XML/JSON API protocol support for read/write relays status;

 Integration protocol:

o SNMPv2 - for smartDEN IP-16R;

o ModBUS TCP - for smartDEN IP-16R-MT;

o MQTT V3.1.1 - for smartDEN IP-16R-MQ;

 Supported by various Home Automation systems like Domoticz, OpenHab,

Home Assistant, Node-Red;

 Supported protocols: ARP, IP, ICMP (ping), DHCP, DNS;

 Watch-Dog Auto-Reboot ICMP (outgoing) function;

 Access protection (by IP and MAC address);

 Option for relays states saving and loading on reset;
