smartDEN IP-16R-XX User Manual
13 Apr 2021
-41-
10. Integration protocols
10.1. SNMP (for smartDEN IP-16R only)
smartDEN IP-16R supports SNMPv1 protocol – snmpget and snmpset. Most of
the parameters can be configured/read via these commands. Read-only community
string is used for reading and Read-Write Community String is used for changing the
parameters. Parameters that can be changed, are grouped according to their
functions in the tables below. To obtain a valid OID number it is necessary to replace
the "x" symbol with the prefix ".1.3.6.1.4.1.42505". Also all the snmp commands are
described in the MIB file.
During SNMP access, it must be used snmpget and snmpset only to one
OID and not to group of OIDs.
10.1.1. Product
Table 10.1. Product parameters
OID
Name
Access
Description
Syntax
x.6.1.1.0
Name
read-only
Description of the module
DISPLAYSTR
ING
x.6.1.2.0
Version
read-only
Current firmware version
DISPLAYSTR
ING
x.6.1.3.0
Date
read-only
Current firmware version
build date
DISPLAYSTR
ING
10.1.2. Setup
Table 10.2. Setup
Start OID
End OID
Name
Access
Description
Syntax
x.6.2.1.0
...
SystemDate
read-
write
System Date
(dd/mm/yyyy)
DISPLAYST
RING
x.6.2.2.0
...
SystemTime
read-
write
System Time
(hh:mm)
DISPLAYST
RING
x.6.2.3.1.2.0
x.6.2.3.1.2.15
RelayName
read-
write
Relay Name
(maxlen=7)
DISPLAYST
RING (SIZE
(0..7))
x.6.2.3.1.3.0
x.6.2.3.1.3.15
RelayState
read-
write
Relay State
(off-0, on-1)
INTEGER
{off(0), on(1)
}
x.6.2.3.1.4.0
x.6.2.3.1.4.15
RelaySetPul
sePeriod
read-
write
Relay Set
Pulse Period
(0..65535),
ms(x100)
INTEGER32
(0..65535)
x.6.2.3.1.5.0
x.6.2.3.1.5.15
RelayStartPu
lse
read-
write
Relay Start
Pulse
(0..65535),
ms(x100)
INTEGER32
(0..65535)
