AVR-3803/1083/AVC-3570
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks
Q'ty
New
1 1U- 3469 POWER UNIT ASS’Y for EU,EC 1
1 1U- 3469 B POWER UNIT ASS’Y for E2 1
1 1U- 3469 A POWER UNIT ASS’Y for E1,E1H 1
1 1U- 3469 F POWER UNIT ASS’Y for E1C,E1K 1
1 1U- 3469 E POWER UNIT ASS’Y for EUT 1
1 1U- 3469 D POWER UNIT ASS’Y for JP 1
1-1 POWER UNIT
1-2 H/P UNIT
1-3 P.SW-1 UNIT for EU,EC,JP
1-4 VOL.SEL-1 UNIT for E1,E1H
1-5 VOL.SEL-2 UNIT for E1,E1H
1-6 PRE OUT UNIT
2 1U- 3470
CONNECT/VIDEO UNIT ASS’Y
for EU,EC 1
2 1U- 3470 A
CONNECT/VIDEO UNIT ASS’Y
for E2,E1,E1C,
E1H,EUT,E1K 1
2 1U- 3470 D
CONNECT/VIDEO UNIT ASS’Y
for JP 1
2-1 CONNECT UNIT
2-2 FRONT UNIT
2-3 S-VIDEO UNIT
2-4 C-VIDEO UNIT
2-6 REMOTE I/O UNIT
2-7 VCONNECT UNIT
3 1U- 3471 CONTROL UNIT ASS’Y for EU,EC 1
3 1U- 3471 B CONTROL UNIT ASS’Y for E2 1
3 1U- 3471 A CONTROL UNIT ASS’Y for E1,E1H 1
3 1U- 3471 E CONTROL UNIT ASS’Y for E1C,EUT,E1K 1
3 1U- 3471 D CONTROL UNIT ASS’Y for JP 1
3-1 CONTROL UNIT
3-2 DISPLAY UNIT
3-3 VOL UNIT
4 1U- 3472
AMP CONNECT UNIT ASS’Y
for EU,EC 1
4 1U- 3472 B
AMP CONNECT UNIT ASS’Y
for E2 1
4 1U- 3472 A
AMP CONNECT UNIT ASS’Y
for E1,E1H 1
4 1U- 3472 F
AMP CONNECT UNIT ASS’Y
for E1C,E1K 1
4 1U- 3472 E
AMP CONNECT UNIT ASS’Y
for EUT 1
4 1U- 3472 D
AMP CONNECT UNIT ASS’Y
for JP 1
4-1 REGULATOR UNIT
4-2 AMP CONNECT UNIT
4-3 AC IN UNIT
4-4 EXT.IN CONN.UNIT
4-5 TU CONNECT UNIT for EU,EC,E2,E1,
E1C,E1H,EUT,E1K
4-6 AUDIO CONN. UNIT
4-7 P.SW-2 UNIT for E2,E1,E1C,
E1H,EUT,E1K
5 1U- 3473
AUDIO/DIGITAL UNIT ASS’Y
for EU,EC,E1,
E1C,E1H,E1K 1
5 1U- 3473 B
AUDIO/DIGITAL UNIT ASS’Y
for E2,EUT 1
5 1U- 3473 D
AUDIO/DIGITAL UNIT ASS’Y
for JP 1
5-1 DIGITAL UNIT
5-2 AUDIO IN UNIT
5-3 EXT IN VR UNIT
6 1U- 3474 DSP UNIT 1
7 1U- 3475 VIDEO UNIT ASS’Y for EU,EC 1
7 1U- 3475 B VIDEO UNIT ASS’Y
for E2,E1C,EUT,E1K
1
7 1U- 3475 A VIDEO UNIT ASS’Y for E1,E1H 1
7 1U- 3475 D VIDEO UNIT ASS’Y for JP 1
7-1 CONVERT UNIT
7-2 COMP. D4 UNIT for JP
7-3 COMP.VIDEO UNIT for EU,EC,E2,E1,
E1C,E1H,EUT,E1K
8 411 1372 937 MAIN CHASSIS 1
9 412 4692 109 TRANS BRACKET 1
10 412 4210 002 BRACKET 2
11 412 4716 014 SUPPORT BRACKET 1
∗
12 104 0194 289 FOOT ASS’Y for EU,EC,E2,E1,
E1C,E1H,EUT,E1K
4
12 104 0173 213 FOOT ASS’Y for JP 4
13 412 3548 005 P.W.B CATCHER 3
14 412 2814 028 CARD SPACER(L=10) 4
15 206 2160 009 AC CORD VH N/I E3 for EU,EC,GUT 1
15 206 2089 106 AC CORD W/CON.E2 for E2 1
15 206 2175 007 AC CORD(E1/VH) for E1 1
15 206 2174 008 AC CORD(E1C/VH) for E1C 1
15 206 2177 005 AC CORD(EK/VH) for E1H 1
15 206 2178 004 KOREA AC CORD VH for E1K 1
16 412 2955 107 SIDE BRACKET for E2,E1,E1C,
E1H,E1K 1
17 412 2814 028 CARD SPACER(L=10) for EU,EC,E2,
E1C,EUT,E1K,JP 10
17 412 2814 028 CARD SPACER(L=10) for E1,E1H 11
18 461 0573 062 RUBBER SHEET 1
∗
19 461 0714 009 CUSHION(B) 1
20 414 0978 001 SHIELD PLATE (A) 1
21 412 2814 031 CARD SPACER (L=4) for EU,EC,E2,E1,
E1C,E1H,EUT,E1K
1
22 412 2814 099 CARD SPACER (L=2.5) 1
23 412 2741 052 P.W.B HOLDER(H=22) 1
24 412 2404 056 PWB HOLDER (WLS-18) 1
∗
25 414 0979 000 SHIELD PLATE (B) 1
26 409 0052 019 HOLDER (A) 1
27 412 2404 069 PWB HOLDER (WLS-12) 1
∗
28 461 0639 003 RUBBER SHEET 1
29 203 2374 090 2P VA-VA CABLE for E2,E1,E1C,
E1H,EUT,E1K 1 *
30 105 1417 104 BACK PANEL
for AVR-3803EU,EC
1
∗
30 105 1417 117 BACK PANEL for AVR-1083EU 1
∗
30 105 1417 120 BACK PANEL for E2 1
∗
30 105 1417 133 BACK PANEL for E1,E1H 1
∗
30 105 1417 146 BACK PANEL for E1C 1
∗
30 105 1417 162 BACK PANEL for EUT 1
∗
30 105 1417 159 BACK PANEL for E1K 1
∗
30 105 1417 175 BACK PANEL for JP 1
∗
31 449 0070 002 LOCKING CARD SPACER for EU,EC,E2,E1,
E1C,E1H,EUT,E1K
1
32 445 0056 008 CORD BUSH for EU,EC,E2,E1,
E1C,E1H,EUT,E1K
1
33 205 1116 006 TERMINAL ASS’Y 1
Note : The symbols in the column “Remarks” indicate the following destinations.
EU : U.S.A. model E1C : China model
EC : Canada model E1H : Hong Kong model
E2 : Europe model EUT : Taiwan R.O.C. model
E1 : Asia model E1K : Korea model
JP : Japan model
