Denon AVC-A110 User Manual

o
Example connection when using one set of Dolby Atmos Enabled speakers
.
C
SBL
SBR
SW
SL SR
FL
FR
FDL FDR
0
Set “Floor” - “Layout” to “5ch & SB” and “Dolby Sp” to “2ch” in the menu when
connecting in this configuration. (v p. 229, 230)
.
FDR FDL
HEIGHT 1
z
SW
SBR SBL
FR FL C SR SL
z
The surround Dolby or back Dolby speakers can be connected instead of the
front Dolby speakers. In this case, set the Dolby Atmos Enabled speakers to be
connected under “Height” - “Layout” in the menu. (v p. 231)
Contents
Connections Playback Settings Tips Appendix
59
Front panel Display Rear panel Remote Index

Denon AVC-A110 Specifications

General

Brand	Denon
Model	AVC-A110
Category	Amplifier
Language	English
