Denon AVC-A1H User Manual

o
Subwoofer
Set the presence of a subwoofer.
Yes
(Default):
Use a subwoofer.
No:
Select when a subwoofer is not
connected.
0
When “Speaker Configuration” - “Subwoofer” in the menu is set to “None”, No
is automatically set. (v p. 225)
If the “Front” setting is “Small”, the setting is automatically “Yes”.
o
Subwoofer Output
Selects which low frequency signals are sent to the subwoofer outputs.
LFE
(Default):
When “2ch Playback” - “Front” is set to
“Large”, only LFE signals are output from
the subwoofer. Also, when “2ch
Playback” - “Front” is set to “Small”, the
front channel low range signals are
added to the LFE signals and output from
the subwoofer.
LFE + Main:
The front channel low range signal is
added to the LFE signal output from the
subwoofer.
0
This can be set when “2ch Playback” - “Subwoofer” is set to “Yes”.
Contents Connections Playback Settings Tips Appendix
239
Front panel Display Rear panel Remote Index

Denon AVC-A1H Specifications

General

Channels	15.4
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% 2ch Drive)
HDMI Outputs	3
Audio Formats	Dolby Atmos, DTS:X, Auro-3D, IMAX Enhanced
Wireless Connectivity	Wi-Fi, Bluetooth
Type	AV Amplifier
IMAX Enhanced	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
THD	0.05%
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	102 dB
Ethernet	Yes
USB Port	Yes
Multi-Room Audio	HEOS
Amplifier Type	Class AB
