Denon AVR-2307CI Service Manual

24
AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
AS7C340096A-10TCN (HDMI : IC806,817)
BA4510F-E2 (HDMI : IC815A,816A)
96VREF VREF --- ---ADref.+5V
97AVCC AVCC --- ---AD+5V
98 P97/SIN4 SHARCSDIN I - Lv - Eu Z DSPcontrolpin(ADSP-21366)IC804MISO126SHARCSDIN
99 P96/SOUT4 SHARCSDOUT O C - - - Z DSPcontrolpin(ADSP-21366)IC804MISI127SHARCSDOUT
100 P95/CLK4 SHARCSCLK O C - - - Z DSPcontrolpin(ADSP-21366)IC804SPICLK125SHARCSCLK
Pin PinName Symbol I/O Type Det
Op
(Int.)
Op
(Ext.)
Res FUNCTION
+
+
1
2
3
4
8
7
6
5
OUT1
Ð IN1
+ IN1
V
EE
VCC
OUT2
Ð IN2
+ IN2
1ch
2ch
Ð
Ð
