13
AVR-1909/789, AVC-1909
6. VIDEO P.W.B ASSY
(1) Disconnect the connector wires and boards.（コネクタワイヤーとコネクタボードをはずす。）
7. INPUT / CPU P.W.B ASSY
(1) Disconnect the FFC cable.（FFC ケーブルをはずす。）
proceeding (手順): CABINET TOP → HDMI P.W.B ASSY → SIRIUS P.W.B ASSY
→ TUNER PACK → CHASSIS BACK SUB ASSY
→ VIDEO P.W.B ASSY
VIDEO P.W.B ASSY
Picture D
Board to board
CP2010
SUPPORTER
CP2009CP2008Board to board
proceeding (手順): CABINET TOP → HDMI P.W.B ASSY → SIRIUS P.W.B ASSY
→ TUNER PACK → CHASSIS BACK SUB ASSY
→ VIDEO P.W.B ASSY → INPUT / CPU P.W.B ASSY
FFC CABLE
Picture C
CPU P.W.B ASSY
