15
AVR-1909/789, AVC-1909
8. MAIN P.W.B SUB ASSY
9. POWER P.W.B SUB ASSY
(1) Disconnect the connector wires and boards.(コネクタワイヤーとコネクタボードをはずす。
proceeding (手順): CABINET TOP HDMI P.W.B ASSY SIRIUS P.W.B ASSY
MAIN P.W.B SUB ASSY
TUNER PACK CHASSIS BACK SUB ASSY
VIDEO P.W.B ASSY INPUT / CPU P.W.B ASSY
Please refer to "EXPLODED VIEW " for the disassembly method of each P.W.B included in MAIN P.W.B ASSY .
MAINP.W.BASSY の各基板のはずしかたは "EXPLODEDVIEW" を参照してください。
proceeding (手順): CABINET TOP HDMI P.W.B ASSY SIRIUS P.W.B ASSY
TUNER PACK CHASSIS BACK SUB ASSY
POWER P.W.B SUB ASSY
Picture C
cut cut
CP513 CP512
CP504
CP503CP501
Board to board
POWER P.W.B ASSY
POWER SUPPLY P.W.B ASSY
Please refer to "EXPLODED VIEW " for the disassembly method of each P.W.B included in POWER P.W.B SUB ASSY.
POWERP.W.BSUBASSY の各基板のはずしかたは "EXPLODEDVIEW" を参照してください。
