Denon AVR-988 Service Manual

132
AVR-2808CI / AVR-988
7-4 FUNC UNIT 1
7-5 LED UNIT 1
7-6 VOL UNIT B 1
7-7 JOINT UNIT 1
7-8 FRONT IN UNIT 1
7-9 MIC UNIT 1
7-10 REMOTE/IPOD UNIT 1
7-11 DIGITAL I/O UNIT 1
7-12 V/D JOINT UNIT 1
7-13 UCON CONNECT UNIT 1
7-14 P.SW B 1
7-15 FFC LOCK UNIT 1
11 00D 144 3030 005 FRONT PANEL 2808CIEU,2808CIEC 1 *
11 00D 144 2990 010 FRONT PANEL 988EU 1 *
12 nsp DENON BADGE 1
13 nsp LENS 3
14 00D 144 3031 004 DOOR 2808CIEU,2808CIEC 1 *
14 00D 144 2976 034 DOOR 988EU 1 *
15 00D 401 0195 202 HINGE (L) 1
16 00D 401 0196 201 HINGE (R) 1
17 00D 114 0204 008 KNOB RING(M) 2808CIEU,2808CIEC 1
18 00D 114 0203 009 KNOB RING(F) 2808CIEU,2808CIEC 1
19 00D 112 1005 006 KNOB(M) ASSY 2808CIEU,2808CIEC 1
19 00D 112 0929 002 KNOB(M) ASSY 988EU 1
20 00D 112 1007 004 KNOB(F) ASSY 2808CIEU,2808CIEC 1
20 00D 112 0931 003 KNOB(F) ASSY 988EU 1
21 00D 146 2509 148 INNER PANEL 2808CIEU,2808CIEC 1 *
21 00D 146 2451 005 INNER PANEL 988EU 1 *
22 00D 143 1295 001 DOOR SHEET 2808CIEU,2808CIEC 1 *
22 00D 143 1295 043 DOOR SHEET 988EU 1 *
23 nsp RUBBER SHEET DOOR CLOSE 2
24 nsp RUBBER SHEET DOOR OPEN 2
25 00D 143 1294 002 WINDOW 2808CIEU,2808CIEC 1 *
25 00D 143 1241 149 WINDOW 988EU 1 *
26 00D 113 1996 202 CURSOR KNOB 1
27 00D 113 1995 041 ENTER KNOB 1
28 nsp LENS (POWER) 1
29 00D 113 1992 109 P.KNOB ASSY(SUB) 1
30 00D 113 1994 107 P.KNOB ASSY(MAIN) 1
31 00D 421 0763 010 GEAR DAMPER 058E-L 1
32 nsp DOOR STOPPER 1
33 nsp FRONT BRACKET 2808CIEU,2808CIEC 1
34 00D GEN 8688 TOP COVER SUB ASSY 00D1020704000 1
35 nsp MAIN CHASSIS 2808CIEU,2808CIEC 1
35 nsp MAIN CHASSIS 988EU 1
36 nsp BRACKET 2
37 nsp FOOT 4
38 nsp RUBBER PAD 4
39 nsp SUPPORT BRACKET 1
40 nsp SCREW COVER (BOTTOM) 1
! 42 00D 233 6616 001 POWER TRANS (E3) 1 *
43 00D 105 1693 106 BACK PANEL 2808CIEU,2808CIEC 1 *
43 00D 105 1693 119 BACK PANEL 988EU 1 *
44 00D 216 0124 002 AM FM TUNER(E3) 1
Ref. No. Part No. Part Name Remarks Q'ty New
