Denon AVR-S500BT User Manual

Use the illustration below as a guide for how high each speaker should be installed.
The height does not need to be exactly the same.
.
GViewed from the sideH
Surround
speaker
Front
speaker
o
When 5.1-channel speakers are installed
.
z1
z2
FL
SW
C
SL
FR
SR
z
1:22° - 30°
z
2:120°
