Denon AVR-S540BT Service Manual

This is not used during servicing. Do not use.
3-5.1. Operations
Exit the PIMG Version Display Mode.
Remove the power plug to exit this mode.
PMIG :********
4.1. Actions
Switches the panel lock mode.
4.2. Starting up
Press "
TUNER PRESET CH -
" and "
QUICK SELECT 3
" simultaneously while on standby.
Panel LOCK:On
4.3. Canceling the selected mode
Press "
TUNER PRESET CH -
" and "
QUICK SELECT 4
" simultaneously while on standby.
Panel LOCK:Off
3-5. PIMG Version Display Mode 4. Front Panel Lock Mode
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
74

Denon AVR-S540BT Specifications

General

Channels	5.2
Power Output per Channel	70 W (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
HDMI Inputs	5
HDMI Outputs	1
HDMI Version	2.0a
HDCP Support	2.2
4K/60 Hz Pass-through	Yes
Dolby Format	Dolby TrueHD, Dolby Digital Plus
DTS Format	DTS-HD Master Audio
Auto Speaker Setup	Yes (Audyssey MultEQ)
Bluetooth	Yes
FM Tuner	Yes
AM Tuner	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
Dimensions (W x H x D)	434 x 151 x 319 mm
Ethernet Port	No
Wi-Fi	No
HDR Support	HDR10, HLG
Frequency Response	10 Hz - 100 kHz - +1/-3 dB
Total Harmonic Distortion	0.08% (20 Hz - 20 kHz)
Signal-to-Noise Ratio	98 dB (IHF-A weighted)
USB Port	Yes (Front)
