Denon AVR-S540BT Service Manual

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
While holding down buttons "
TUNE +
" and "
DIMMER
" simultaneously, press the power button to turn
on the power.
then press the "
STATUS
" button to display the information in section 1.3 on the display.
1.3. Display Order
Error information(See "1.4. Error display") →
q
Model destination information
→
w
Main µ-com →
e
Main IAP →
r
DSP version →
t
OSD version →
y
4k GUI version
→
u
Bluetooth version
q
Model destination information :
AVR-X250 \\\ *
\
: Region (E3, E2, E1C, JP)
w
Main µ-com :
Main :**.**
e
Main IAP :
Main IAP V**.**
r
DSP version :
DSP.*.*.*
t
OSD version :
OSD :**.**
y
4k GUI version :
PIMG :********
u
Bluetooth version :
BT.**.**.**
1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
Condi-
tion
States Display
DSP NG Cannot execute DSP reset in DSP code boot.
DSP ERROR 01
DSP OK - (No Error display)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
69

Denon AVR-S540BT Specifications

General

Channels	5.2
Power Output per Channel	70 W (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
HDMI Inputs	5
HDMI Outputs	1
HDMI Version	2.0a
HDCP Support	2.2
4K/60 Hz Pass-through	Yes
Dolby Format	Dolby TrueHD, Dolby Digital Plus
DTS Format	DTS-HD Master Audio
Auto Speaker Setup	Yes (Audyssey MultEQ)
Bluetooth	Yes
FM Tuner	Yes
AM Tuner	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
Dimensions (W x H x D)	434 x 151 x 319 mm
Ethernet Port	No
Wi-Fi	No
HDR Support	HDR10, HLG
Frequency Response	10 Hz - 100 kHz - +1/-3 dB
Total Harmonic Distortion	0.08% (20 Hz - 20 kHz)
Signal-to-Noise Ratio	98 dB (IHF-A weighted)
USB Port	Yes (Front)
