Denon AVR-S540BT User Manual

o
No sound comes out
Symptom Cause / Solution Page
No sound comes out of
speakers.
0
Check the connections for all devices. 22
0
Insert connection cables all the way in. －
0
Check that input connectors and output connectors are not reversely connected. －
0
Check cables for damage. －
0
Check that speaker cables are properly connected. Check that cable core wires come in contact with the
metal part on speaker terminals.
22
0
Securely tighten the speaker terminals. Check speaker terminals for looseness. 22
0
Check that a proper input source is selected. 38
0
Adjust the volume. 39
0
Cancel the mute mode. 39
0
Check the digital audio input connector setting. 81
0
Check the digital audio output setting on the connected device. On some devices, the digital audio output
is set to off by default.
－
0
When a headphone is plugged into the PHONES jack on the main unit, sound is not output from the
speaker terminal and SUBWOOFER connector.
12
No sound comes out when
using the DVI-D
connection.
0
When this unit is connected to a device equipped with a DVI-D connector, no sound is output. Make a
separate audio connection.
－
Contents Connections Playback Settings Tips Appendix
103
Front panel Display Rear panel Remote Index

Denon AVR-S540BT Specifications

General

Channels	5.2
Power Output per Channel	70 W (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
HDMI Inputs	5
HDMI Outputs	1
HDMI Version	2.0a
HDCP Support	2.2
4K/60 Hz Pass-through	Yes
Dolby Format	Dolby TrueHD, Dolby Digital Plus
DTS Format	DTS-HD Master Audio
Auto Speaker Setup	Yes (Audyssey MultEQ)
Bluetooth	Yes
FM Tuner	Yes
AM Tuner	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
Dimensions (W x H x D)	434 x 151 x 319 mm
Ethernet Port	No
Wi-Fi	No
HDR Support	HDR10, HLG
Frequency Response	10 Hz - 100 kHz - +1/-3 dB
Total Harmonic Distortion	0.08% (20 Hz - 20 kHz)
Signal-to-Noise Ratio	98 dB (IHF-A weighted)
USB Port	Yes (Front)
