Page #135 background imageLoading...
Page #135 background image
o
HDMI PassThrough
Selects how this unit will transmit HDMI signals to the HDMI output in
standby power mode.
On
(Default):
Transmits the selected HDMI input
through this unit’s HDMI output when this
unit is in standby power mode.
Off:
No HDMI signals are transmitted through
this unit’s HDMI output in standby power
mode.
o
Pass Source
Sets the HDMI connector that inputs HDMI signals when in standby.
Last:
The most recently used input source will
go into standby mode.
CBL/SAT / Media Player /
Blu-ray / Game / AUX1 /
AUX2 / TV Audio
(Default: CBL/SAT)
Pass through the selected input source.
0
“Pass Source” can be set when “HDMI PassThrough” is set to “On” or “HDMI
Control” is set to “On”. (“HDMI PassThrough” (v p. 135), “HDMI
Control” (v p. 136))
o
RC Select
Set whether to allow this unit to be turned on by the input source select
button on the remote control when this unit is on standby.
Power On+Source
(Default):
The power of this unit is turned on and
the input source changes.
Source Only:
The HDMI input source changes while
this unit is on standby. The power display
of this unit blinks when the input source
select button of the remote control is
pressed.
0
“RC Select” can be set when “HDMI Control” is set to “On” or “HDMI
PassThrough” is set to “On”. (“HDMI PassThrough” (v p. 135), “HDMI
Control” (v p. 136))
Contents Connections Playback Settings Tips Appendix
135
Front panel Display Rear panel Remote Index
