Denon AVR-S730H User Manual

.
oQ0iu
trqw e y
A
Power operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v
p. 62)
B
Power indicator
This is lit as follows according to the power status:
0
Green: Power on
0
Off: Normal standby
0
Red:
0
When “HDMI PassThrough” is set to “On” (v
p. 147)
0
When “HDMI Control” is set to “On” (v p. 148)
0
When “Network Control” is set to “Always On” (v p. 183)
C
SOURCE SELECT knob
This selects the input source. (v
p. 62)
D
Remote control sensor
This receives signals from the remote control unit. (v p. 9)
E
Display
This displays various pieces of information. (v
p. 18)
F
MASTER VOLUME knob
This adjusts the volume level. (v
p. 63)
G
ZONE2 ON/OFF button
This turns the power of ZONE2 (separate room) on/off. (v
p. 126)
H
ZONE2 SOURCE button
This selects the input source for ZONE2. (v
p. 126)
I
Tuner preset channel buttons
(TUNER PRESET CH +, –)
These select preset broadcast stations. (v p. 76)
J
Tuning up / Tuning down buttons (TUNE +, –)
Select either FM broadcast or AM broadcast. (v p. 73)
Contents
Connections Playback Settings Tips Appendix
16
Front panel Display Rear panel Remote Index

Denon AVR-S730H Specifications

General

Channels	7.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	110W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	165W
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
DTS Virtual:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
4K Ultra HD Pass-through	Yes
HDR Support	Yes (HDR10, Dolby Vision, HLG)
Auto Speaker Calibration	Audyssey MultEQ
AirPlay	Yes (AirPlay 2)
Internet Radio	Yes
Phono Input	No
Ethernet Port	Yes
Power Output per Channel	75W (8 ohm, 20Hz-20kHz, 0.08% 2ch Drive)
USB Input	1 (Front)
