Denon AVR-S960H User Manual

o
Speaker Selection
Select whether to adjust tones for individual speakers or for all
speakers.
All: Adjust all speaker tones together.
Left/Right
(Default):
Adjust the left and right speaker tones
together.
Each: Adjust the tone for each speaker.
o
Adjust EQ
Adjust tonal balance for each frequency band.
1. Select the speaker.
2. Select the adjustment frequency band.
63 Hz / 125 Hz / 250 Hz / 500 Hz / 1 kHz / 2 kHz / 4 kHz / 8 kHz /
16 kHz
3. Adjust the level.
–20.0 dB – +6.0 dB (Default: 0.0 dB)
0
Front Dolby and Surround Dolby speakers can only be set when
63 Hz/125 Hz/250 Hz/500 Hz/1 kHz.
o
Curve Copy
Copy the Flat correction curve created in Audyssey
®
Setup.
0
“Curve Copy” is displayed after Audyssey
®
Setup has been performed.
0
“Curve Copy” cannot be used when using headphones.
o
Set Defaults
The “Graphic EQ” settings are returned to the default settings.
Contents Connections Playback Settings Tips Appendix
160
Front panel Display Rear panel Remote Index

Denon AVR-S960H Specifications

General

Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS:X
Volume control	Rotary
Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W
Package weight	11500 g
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	7
Audio (L/R) in	4
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
3D	-
Package depth	429 mm
Package width	520 mm
Package height	243 mm

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
