Denon AVR-X540BT Quick Start Guide

9
Owner’s Manual
•For more information, visit www.denon.com
•Refer to the Online Manual for other functions
information and operation procedure details.
manuals.denon.com/AVRX540BT/EU/EN/
Compatible with the
“Denon 500 Series
Remote” App
The “Denon 500 Series Remote” App allows you to
remotely control the AVR-X540BT from your mobile device
when connected via Bluetooth. It is available for free in the
Apple App Store, Google Play or the Amazon Appstore.
Make sure you search for “DENON 500 SERIES”.
PDF
Overview
Connections
Playback
Settings
Tips
Appendix
PDF Download
AV SURROUND RECEIVER
AV SURROUND RECEIVER
WEB Manual
Copyright © 2017 D&M Holdings Inc. All Rights Reserved.
AVR-X540BT
Contents
English
Online Manual
1. AVR-X540BTE2_QSG_ENG_00A.indd 9 2017/02/17 11:33:28
PrintingColor:Black

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
