Denon AVR-X540BT Quick Start Guide

8
4
Enjoying music using Bluetooth
1
Press and hold the Bluetooth button on the remote
control for at least 3 seconds to go into pairing
mode.

2
Activate the Bluetooth settings on your mobile
device.

Bluetooth ON
3
Select “Denon AVR-X540BT” from the Bluetooth
device list on your mobile device.

Denon AVR-X540BT
Bluetooth
4
When a number appears on the display of this unit,
check that it is the same number as that shown on
the screen of the Bluetooth device and then select
“Pair” for both the Bluetooth device and the unit.
5
Play music using any App on your device.
To reconnect a previously paired Bluetooth
device, Start at step 2.
1. AVR-X540BTE2_QSG_ENG_00A.indd 8 2017/02/17 11:33:27
PrintingColor:Black

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
