Denon AVR-X540BT User Manual

TP search
TP identifies programs that carry traffic announcements.
This allows you to easily find out the latest traffic conditions in your area
before leaving home.
Use this function to find RDS stations broadcasting traffic programs (TP
stations).
1
Press FM when the input source is “Tuner”.
2
Press OPTION.
The option menu screen is displayed.
3
Use ui to select “TP Search”, then press ENTER.
4
Press ENTER.
TP search begins automatically.
Radio Text
RT allows RDS stations to send text messages that appear on the display.
“Radio text” appears on the display when radio text data is received.
1
Press FM when the input source is “Tuner”.
2
Press OPTION.
The option menu screen is displayed.
3
Use ui to select “Radio Text”, then press ENTER.
4
Use o p to select “On”, then press ENTER.
0
While receiving an RDS broadcast station, the text data
broadcast from the station is displayed.
0
If no text data is being broadcast, “NO TEXT DATA” is displayed.
Contents Connections Playback Settings Tips Appendix
51
Front panel Display Rear panel Remote Index

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
