Contents
Tips
I want the volume not to become too loud by mistake 102
I want to keep the volume at the same level when I turn the power on 102
I want to have the subwoofer always output audio 102
I want to set the optimized listening environment after changing the
configuration/position of the speakers or changing a speaker to a new
one 102
I want to combine a desired video with the current music 102
Troubleshooting
Power does not turn on / Power is turned off 104
Operations cannot be performed through the remote control unit 105
Display on this unit shows nothing 105
No sound comes out 106
Desired sound does not come out 107
Sound is interrupted or noise occurs 109
No video is shown on the TV 110
The menu screen is not displayed on the TV 111
USB memory devices cannot be played back 112
File names on the USB memory device are not displayed properly 113
Bluetooth cannot be played back 113
The HDMI control function does not work 114
Contents Connections Playback Settings Tips Appendix
Tips
101
Front panel Display Rear panel Remote Index

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
