Page #54 background image
Skipping preset broadcast stations
(Preset Skip)
Perform auto preset memory to save all the broadcasting stations that can
be received in the memory. Selecting a broadcast station becomes easier
by skipping unnecessary memories.
1
Press OPTION when the input source is “FM” or “AM”.
The option menu screen is displayed.
2
Use ui to select “Preset Skip”, then press ENTER.
The “Preset Skip” screen is displayed.
3
Use ui to select the group of broadcast stations you
want to skip.
Skip all the broadcast stations that are included in the selected
group “Preset z-z”.
(z is the selected group number.)
4
Use o p to select “Skip”.
The station you selected is not displayed.
Cancelling Preset Skip
1
While the “Preset Skip” screen is displayed, use ui to
select a group of a broadcast stations to cancel the
skip for.
2
Use o p to select “On”.
The skip is cancelled.
Contents Connections Playback Settings Tips Appendix
54
Front panel Display Rear panel Remote Index

Other manuals for Denon AVR-X540BT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X540BT and is the answer not in the manual?

Denon AVR-X540BT Specifications

General IconGeneral
Channels5.2
HDMI Inputs5
HDMI Outputs1
BluetoothYes
4K Ultra HD Pass-throughYes
Dolby TrueHDYes
DTS-HD Master AudioYes
Auto Speaker CalibrationNo
Number of Power Amps5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)140 W
Composite In2
Composite Out1
Digital In: Optical2
Analog In2
Speaker Terminal: ScrewYes
FM Tuner with RDSYes
3D Signal Pass-ThroughYes
Audio Return ChannelYes
HDMI Standby Pass-ThroughYes
CECYes
Auto Speaker Setup by MicrophoneNo
Dimensions (W x H x D)434 x 151 x 319 mm
Weight7.5 kg
Total Harmonic Distortion0.08 %
Input Sensitivity/Impedance200 mV / 47 kΩ
Signal-to-Noise Ratio98 dB
Ethernet PortNo
Wi-FiNo
Power Output per Channel70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response10Hz - 100kHz
Supported Audio FormatsMP3, WMA, AAC
