Denon AVR-X550BT Owner's Manual

o
Dynamic Comp.
Compress dynamic range (difference between loud and soft sounds).
Auto:
Automatic dynamic range compression
on/off control according to source.
Low / Medium / High: These set the compression level.
Off:
Dynamic range compression is always
off.
0
“Auto” can only be set when Dolby TrueHD signals are input.
o
Low Frequency
Adjust the low frequency effects level (LFE).
-10 dB – 0 dB (Default : 0 dB)
0
For proper playback of the different sources, we recommend setting to the
values below.
0
Dolby Digital sources : 0 dB
0
DTS movie sources : 0 dB
0
DTS music sources: -10 dB
o
Center Image
Distributes the dialogue output from the center channel to the front left
and right channels and widens the sound image in the front.
0.0 – 1.0 (Default : 0.3)
0
You can set this when the sound mode is DTS Neo:6 in the “Music” mode.
0
The smaller the value, the more dialogue is concentrated on the center
channel. The larger the value, the more dialogue is distributed to front left and
right channels, and the more the sound image widens in the front.
Contents Connections Playback Settings Tips Appendix
75
Front panel Display Rear panel Remote Index

Denon AVR-X550BT Specifications

General

Optical disc player type	-
Built-in HDD	No
Multichannel decoding	Yes
Audio decoders	Dolby Atmos, Dolby Surround, Dolby TrueHD
RMS rated power	130 W
Audio output channels	5.1 channels
Audio formats supported	AAC, FLAC, MP3, WMA
AM band range	522 - 1611 kHz
FM band range	58.5 - 1.8 MHz
Product color	Black
HDMI in	5
Composite video in	2
SCART ports quantity	0
Number of HDMI outputs	1
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Package weight	Weight of the packaged product in gram.

Weight and Dimensions

Main unit weight	7257 g
Main unit dimensions (WxDxH)	431 x 304 x 127 mm
