Denon AVR-X8500H User Manual

4K Signal Format
Set the 4K signal format to be played back by this unit when the TV or
playback device connected to this unit is HDMI 4K (60Hz/50Hz) signal
compatible.
o
4K Signal Format
Set the format of the 4K signal played back by this unit.
Standard
(Default):
Select if your TV and playback devices
support standard 4K 60p 4:2:0 8 bit video
signals.
Enhanced:
Select if your TV, playback devices, and
cables support high quality 4K 60p 4:4:4,
4:2:2 or 4K 60p 4:2:0 10 bit video signals.
GRelation between the “4K Signal Format” setting and supported
resolutionsH
Support
Resolution
Color
Space
Pixel
Depth
4K Signal Format
Enhanced
Standard
(Default)
4K 24p, 4K
30p, 4K 25p
RGB /
YCbCr 4:4:4
8 bit
P P
10,12 bit
P
–
YCbCr 4:2:2 12 bit
P P
4K 60p, 4K 50p YCbCr 4:2:0 8 bit
P P
10,12 bit
P
–
RGB /
YCbCr 4:4:4
8 bit
P
–
YCbCr 4:2:2 12 bit
P
–
Contents Connections Playback Settings Tips Appendix
206
Front panel Display Rear panel Remote Index

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
