Denon CEOL RCD-N11DAB User Manual

.
GFront panelH
Q0 Q1 Q2
oi
H
Disc tray
Used to insert a disc. (v p. 132)
I
Display
This displays various pieces of information.
J
Remote control sensor
This receives signals from the remote control unit. (v p. 8)
K
Disc tray open/close button (5)
Opens and closes the disc tray. (v p. 54)
L
Headphones jack (R)
Used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers.
NOTE
0
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
Contents Connections Playback Settings Tips Appendix
14
Front/Top
panel
Rear panel
Remote control
unit
Index

Denon CEOL RCD-N11DAB Specifications

General

Type	Home audio micro system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Apple docking	-
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical in	2
Channels quantity	2 channels
Disc types supported	CD, CD-R, CD-RW
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Impedance	6 Ω
Speaker type	2-way
Frequency range	50 - 20000 Hz
RMS rated power	- W
Woofer diameter	120 mm
Tweeter diameter	30 mm
Signal-to-Noise Ratio (SNR)	74 dB
Total Harmonic Distortion (THD)	0.7 %
Volume control	Touch
Supported radio bands	AM, DAB, DAB+, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
Power source	AC
Input voltage	230 V
Input frequency	50/60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	55 W
Display type	OLED

Weight and Dimensions

Package type	Box
Package depth	390 mm
Package width	380 mm
Package height	513 mm
Package weight	6000 g
Main unit weight	3400 g
Main unit dimensions (WxDxH)	280 x 305 x 108 mm
